Unishield 90 Proshield X
GENERAL DESCRIPTION
UNISHIELD 90 ProShield X is a unique fireproof door core blank made from multi-layered wooden based products integrated with Unishield fireproof special mineral with fireproof adhesive. An engineered solid core to resist the fire and smoke. Its acoustic property is an additional feature ensuring fire safety & comfort.
END USE & APPLICATION
For single high rise buildings
For Residential, Commercial, Recreational & Industrial Shutters / Doors
Internal & External Doors
APPROVED SIZES
| Thickness | 64 mm |
|---|---|
| Sizes (Height × Width) |
2135x915 mm, 2135x1050 mm, 2135x1075 mm, 2200x1050 mm, 2200x1075 mm, 2200x1100 mm, 2440x1220 mm |
Properties
| Fire Integrity | Insulation | |
|---|---|---|
| Fire Resistent & Insulation | 90 Minutes | 90 Minutes |
| Actual Test Result | 102 Minutes | 102 Minutes |
Acoustic Proof
Up to 45 STC
Hardware
Concealed and Surface mounted
Applied Standards
Compatability
Compatable for all doors types and configurations
